DTH 1UF 100KV 10000VDC
View:86 Time:2025-03
DTH-100kv-1uF impulse voltage capacitor
APPLICATION
1. Insulated casing, small size, light weight, high energy storage density
2. Excellent electrical performance and high reliability.
3. Suitable for use in impulse voltage pulse power supply lines.
Technical and performance indicators
1. Execution standards: JB/T8168-1999
2. Environmental temperature:- 40℃~ +50℃
3. Loss tangent: ≤ 0.0010(100Hz)
4. Rated voltage: 100kv, withstand voltage: 100kv/60s
5. Rated capacity: 1 μ F, accuracy: ± 1%
Application scope
1. Impulse voltage generator

2. Multi level pulse power supply device
